SkyHawk™ leverages Seagate's extensive experience in designing drives purpose-built for surveillance applications.
ImagePerfect™ firmware is designed to ensure seamless video footage capture in 24×7 surveillance workloads1 that record video from 64 HD cameras.
SkyHawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options.2 Included is RAID RapidRebuild™, which provides 3× faster volume rebuilds over traditional RAID rebuilds.
Unparalleled data protection with included 3-year Rescue Data Recovery Services plan, helping protect important video data with Seagate's in-house data recovery services.
RV sensors built in allow drives to maintain performance in multi-bay systems, giving customers the flexibility to scale their systems when more storage is needed.
ATA streaming support enables recordings from up to 64 HD cameras for smooth, uninterrupted footage.
1 M hours MTBF, 3-year limited warranty represents an improved total cost of ownership (TCO) with reduced maintenance costs.
Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions. Tarnish-resistant components help protect drive from environmental elements, increasing field reliability
Features
HDD capacity: 8 TB
Storage drive buffer size: 256 MB
HDD size: 3.5"
Interface: Serial ATA III
Type: HDD
Component for: PC
HDD interface transfer rate: 6 Gbit/s
HDD sustained transfer rate: 180 MiB/s
Uncorrectable Bit Error Rate (UBER): < 1 per 10^14 bits read
Feature: Rotational Vibration (RV) sensors
Feature: 24/7 operation
Feature: RV sensor(s)
Start/stop cycles: 600000
Workload rate limit: 180 TB/year
Mean time between failures (MTBF): 1000000 h
Power
Power consumption (typical): 5.3 W
Power consumption (off): 0.25 W
Power consumption (idle): 3.4 W
Operating voltage: 5 / 12 V
Start-up current: 1.8 A
Operational conditions
Operating temperature (T-T): 0 - 60 °C
Weight & dimensions
Width: 101.6 mm
Height: 26.1 mm
Depth: 147 mm
Weight: 630 g
Other features
Maximum number of cameras supported: 64
Seagate SkyHawk . HDD capacity: 8 TB, Storage drive buffer size: 256 MB, HDD size: 3.5", Interface: Serial ATA III
Seagate
MBR CODE - ST8000VX010
EAN - 8719706028325
