BD-25B-350GPB
The Chieftec CLASSIC Series brings new life to the proven quality and the decade-old success of the UNI Series with a refreshed front panel design on the outside, while upgrading the quality and features on the inside. Built from 0.7 mm sturdy SECC and including toolless drive installation kits, the CLASSIC series is perfect for system builders who value true quality and timeless design.
Design
Material: SECC
Type: PC
Product colour: Black
Supported motherboard form factors: Mini-ATX, Mini-ITX
Number of 3.5" bays: 3
Number of 5.25" bays: 2
Number of 2.5" bays: 1
Number of internal 3.5" bays: 2
Number of external 5.25" bays: 2
Number of expansion slots: 7
Maximum CPU cooler height: 14 cm
Maximum graphics card length: 34 cm
Power supply
Feature: Power supply included
Power supply: 350 W
Ports & interfaces
Feature: Audio input
Feature: Audio output
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Cooling
Number of front fans supported (max): 1
Front fans diameters supported: 80,90 mm
Number of rear fans supported (max): 1
Rear fans diameters supported: 80,90,120 mm
Storage
Supported HDD sizes: 2.5,3.5,5.25"
Weight & dimensions
Width: 198 mm
Depth: 375 mm
Height: 370 mm
Weight: 5.5 kg
Material thickness: 0.7 mm
Packaging data
Package weight: 6.5 kg
Logistics data
Harmonized System (HS) code: 84733080
Other features
Feature: Screws included
Chieftec BD-25B-350GPB. Type: PC, Product colour: Black, Supported motherboard form factors: Mini-ATX, Mini-ITX. Power supply: 350 W. Front fans diameters supported: 80,90 mm, Rear fans diameters supported: 80,90,120 mm. Supported HDD sizes: 2.5,3.5,5.25". Width: 198 mm, Depth: 375 mm, Height: 370 mm
Chieftec
MBR CODE - BD-25B-350GPB
EAN - 0753263076564
