Display
Display diagonal: 57.1 cm (22.5")
Display resolution: 1920 x 1200 pixels
HD type: WUXGA
Native aspect ratio: 16:10
Display technology: LED
Panel type: IPS
Backlight type: LED
Display brightness (typical): 250 cd/m²
Response time: 5 ms
Screen shape: Flat
Supported graphics resolutions: 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Contrast ratio (typical): 1000:1
Maximum refresh rate: 60 Hz
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 16.78 million colours
Pixel pitch: 0.254 x 0.248 mm
Pixel density: 101 ppi
Horizontal scan range: 31 - 75.5 kHz
Vertical scan range: 59 - 61 Hz
Viewable size, horizontal: 48.8 cm
Viewable size, vertical: 29.7 cm
Viewable size diagonal: 57.2 cm
Colour gamut standard: sRGB
Performance
Feature: Flicker-free technology
Multimedia
Number of speakers: 2
RMS rated power: 2 W
Feature: Built-in speaker(s)
Design
Market positioning: Business
Product colour: Black
Feature: Frameless design
Ports & interfaces
Feature: Built-in USB hub
USB hub version: 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type: USB Type-B
Number of upstream ports: 1
USB Type-A downstream ports quantity: 2
VGA (D-Sub) ports quantity: 1
Feature: HDMI
DisplayPorts quantity: 1
Feature: Audio input
Feature: Headphone out
Headphone connectivity: 3.5 mm
Feature: HDCP
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Height adjustment
Adjustable height (max): 14 cm
Feature: Pivot
Pivot angle: -90 - 90°
Feature: Swivelling
Swivel angle range: 0 - 344°
Feature: Tilt adjustment
Tilt angle range: -5 - 35°
Feature: On Screen Display (OSD)
On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish
Power
Energy efficiency class (SDR): C
Energy consumption (SDR) per 1000 hours: 11 kWh
Power consumption (typical): 10.5 W
Power consumption (standby): 0.5 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Energy efficiency scale: A to G
European Product Registry for Energy Labelling (EPREL) code: 346698
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Width (with stand): 499 mm
Depth (with stand): 233 mm
Height (with stand): 333.9 mm
Weight (with stand): 5.5 kg
Width (without stand): 499 mm
Depth (without stand): 53.6 mm
Height (without stand): 321.3 mm
Weight (without stand): 3.4 kg
Packaging content
Feature: Stand included
Cables included: AC, DisplayPort, USB
Sustainability
Feature: Sustainability compliance
Sustainability certificates: ENERGY STAR, EPEAT Climate +, EPEAT Silver, TCO
Other features
Compliance certificates: BIS, BSMI, CB, CCC, CE, China RoHS, EAC, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, cTUVus, VCCI, WEEE
Logistics data
Harmonized System (HS) code: 85285210
EIZO FlexScan EV2360-BK. Display diagonal: 57.1 cm (22.5"), Display resolution: 1920 x 1200 pixels, HD type: WUXGA, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:10, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub, USB hub version: 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black
Eizo
MBR CODE - EV2360-BK
EAN - 4995047055198
